半导体热电器件在通讯领域中的应用非常广泛，可通过控制温度来提高光?？榈男阅芎涂煽啃?，满足了通信领域对热电器件性能的苛刻要求。
-
型号
-
lmax(A)
-
Umax(V)
-
ΔT Max(℃)
-
QCmax(W)
-
W*Lc*Lh*H
-
规格书
-
-
TEM1-090027A-NN-2P
-
2.7
-
11.6
-
80
-
19.4
-
8.2*10.1*11.3*1.1
-
TEM1-037007A-NM-3P
-
0.7
-
5.4
-
80
-
2.1
-
7.82*2.7*3.4*1.4
-
TEM1-020025A-NM-3B
-
2.5
-
3.1
-
80
-
2.5
-
6.5*4.4*5.5*0.75
-
TEM1-054018A-NM-3V
-
1.8
-
8.3
-
80
-
8.6
-
5.3*12.5*12.5*1.3
-
TEM1-022009A-NMH-3P
-
0.9
-
2.8
-
80
-
1.6
-
5*2.8*3.5*1.78
-
TEM1-032018A-NM-2P
-
1.8
-
4.6
-
80
-
5
-
4.5*4.8*5.6*0.9
-
TEM1-045014A-NM-2P
-
1.4
-
6.5
-
80
-
5.7
-
4.15*9.7*10.5*0.9
-
TEM1-030027A-NM-2P
-
2.2
-
3.8
-
80
-
6.5
-
4.1*6*6.7*0.9
-
TEM1-030028A-NM-2B
-
2.8
-
3.9
-
80
-
6.7
-
4*7.5*8.5*0.9
-
TEM1-024020A-NMH-3B
-
1.5
-
3.5
-
80
-
3.1
-
4*5*5.8*1.2
-
TEM1-028014A-NM-3P
-
1.4
-
3.6
-
80
-
3
-
4*4.4*5.1*1.2
-
TEM1-031010A-NM-2V
-
0.9
-
4.5
-
80
-
3.2
-
4*4.1*4.1*0.9
-
TEM1-032016A-NM-3B
-
1.6
-
4.9
-
80
-
4.5
-
3.8*3.9*4.6*0.97
-
TEM1-024020B-NM-3B
-
2
-
3.7
-
80
-
4
-
3.6*5*6*0.95
-
TEM1-020012A-NM-3P
-
1.2
-
3.1
-
80
-
2.5
-
3.35*5.45*6.15*0.75
-
TEM1-015014A-0M-3B
-
1.4
-
1.9
-
80
-
1.7
-
3.2*2.68*3.6*0.95
-
TEM1-030013A-NC-2P
-
1.3
-
3.9
-
80
-
3
-
3.1*5.1*5.85*1
-
TEM1-028010B-NM-2P
-
1
-
4
-
80
-
2.5
-
3.1*3.6*4.5*1
-
TEM1-027016A-NM-3P
-
1.6
-
3.5
-
80
-
2.3
-
3*4.2*4.9*1
-
TEM1-024010C-NM-3B
-
1
-
3.7
-
80
-
2.1
-
2.95*3.05*3.65*0.75
-
TEM1-027010A-NN-3P
-
1
-
1
-
80
-
2.3
-
2.9*4.5*5.2*1
-
TEM1-020007A-NM-3P
-
0.7
-
2.6
-
80
-
1.2
-
2.8*4.35*5.1*0.9
-
TEM1-020016C-NM-3P
-
1.6
-
2.6
-
80
-
2.5
-
2.8*4.35*5.1*0.9
-
TEM1-025015A-NM-3P
-
1.5
-
3.8
-
80
-
1.8
-
2.3*4.1*4.85*0.9
-
TEM1-018010B-NM-3B
-
1
-
2.6
-
80
-
1.6
-
2*2*2.7*0.8
-
TEM1-012012B-NM-3B
-
1.2
-
1.7
-
80
-
1.2
-
2*2*2.7*0.8
-
TEM1-015010A-NM-3B
-
1
-
1.9
-
80
-
1.2
-
1.8*2*2.6*0.8
-
TEM1-010012A-NM-3B
-
1
-
1.5
-
80
-
1
-
1.8*2*2.6*0.8
-
TEM1-012012A-NM-3B
-
1.2
-
1.6
-
80
-
1.2
-
1.6*2.4*3*0.8
-
TEM1-008012A-NM-3B
-
1.2
-
1
-
80
-
0.7
-
1.6*1.6*2.2*0.9
-
TEM1-010010B-NM-3B
-
1
-
1.3
-
80
-
0.8
-
1.52*2*2.6*0.8
-
TEM1-007010A-NM-3B
-
1
-
0.9
-
80
-
0.6
-
1.25*2.1*2.65*0.8
-
TEM1-014009A-NM-3B
-
0.9
-
2
-
80
-
1.1
-
1.38*2.8*3.2*0.9
-
